Inputu data (DC)

Max. recommended PV

power(for module STC)

45000W

60000W

75000W

90000W

Max.DC voltage

1100V

Start voltage

250V

Nominal voltage

600V

MPPT voltage range

200V-1000V

No. of MPP trackers

3

No. of PV strings per MPP tracker

3/3/2

3/3/3

4/3/3

4/4/4

Max. input current per MPP tracker

37.5A/37.5A/25A

37.5A/37.5A/37.5A

50A/37.5A/37.5A

50A/50A/50A

Max. short-circuit current

per MPP tracker

45A

45A

55A

55A

Output data (AC)

Rated AC output power

30000W

40000W

50000W

60000W

Max. AC apparent power

33300VA

44400VA

55500VA

66600VA

Nominal AC voltage（range*）

230V/400V (340-440V)

AC grid frequency（range*）

50/60 Hz (45-55Hz/55-65 Hz)

Max. output current

48.3A

64.4A

80.5A

96.6A

Adjustable power factor

0.8leading ...0.8lagging

THDi

<3%

AC grid connection type

3W+N+PE

Efficiency

Max. efficiency

98.7%

98.7%

98.7%

98.8%

European efficiency

98.4%

98.5%

98.5%

98.5%

MPPT efficiency

99.9%

Protection devices

DC reverse polarity protection

Yes

DC switch

Yes

AC/DC surge protection

Type II / Type II

Insulation resistance monitoring

Yes

AC short-circuit protection

Yes

Ground fault monitoring

Yes

Grid monitoring

Yes

Anti-islanding protection

Yes

Residual-current monitoring unit

Yes
