Module Type                                                                           182-54FBB

Maximum Power (Pmax/W)

395

400

405

405

Open-circuit Voltage (Voc/V)

34.6

36.8

 37.0

 37.0

Maximum Power Voltage (Vmp/V)

31.1

31.3

31.5

31.5

Short-circuit Current (Isc/A)

13.42

13.48

13.54

13.54

Maximum Power Current (Imp/A)

 12.69

12.77

12.85

 12.85

Module Effiffifficiency (%)

20.23

20.48

20.74

20.74

Power Tolerance: 0~+5W, Temperature Coefficient of Isc: 0.05%/°C, Temperature Coefficient of Voc: -0.31%/°C, Temperature Coefficient of Pmax: -0.35%/°C

Standard Test Environment : Irradiance 1000W/m2, Cell temperature 25°C, Spectrum AM1.5
